Good Performance Industrial Ginger Washing And Drying Machine

FOB Reference Price:Get Latest Price
$6,000.00 - $20,000.00 / Set | 1 Set/Sets (Min. Order)
Model Number:
JME6500/8000/10000
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 25 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets) Less
Report Suspicious Activity
Overview
Quick Details
Applicable Industries:
Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
After Warranty Service:
Video technical support
Local Service Location:
None
Showroom Location:
None
Condition:
New
Place of Origin:
Tianjin, China
Brand Name:
China Joy Machinery
Type:
Washer
Voltage:
380/415/420/440/450V
Power:
30kw
Weight:
2000kgs
Dimension(L*W*H):
6500*1600*2200mm
Certification:
CE/ISO9001
Year:
CE
Product name:
Good Performance Industrial Ginger Washing And Drying Machine
Material:
304 Stainless Steel
Capacity:
1-10 ton/H
Machine part 1:
Air Bubble washing machine
Machine part 2:
High pressure spraying cleaning
Warranty:
12months, 12months
Package:
Standard Wooden Case
Feature:
High Efficiency and capacity Labor and water Saving
Function:
Ginger turmeric washing machine
Water consumption:
3m3/h
Supply Ability
Supply Ability:
200 Set/Sets per Month Good Performance Industrial Ginger Washing And Drying Machine
Packaging & Delivery
Packaging Details
Wooden Case,Standard Export Package.
Port
Tianjin,Shanghai, Qingdao, Ningbo,Guangzhou, Shenzhen,China
Picture Example:
package-img
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 25 To be negotiated
Video Description



Brief Introduction:

The ginger washing machine is our special manufactured equipment suitable for cleaning ginger with high capacity and no damage to the big gingers.

The machine is coming with air bubble cleaning part and high pressure spraying parts.

Also configured with filter conveyor which could take out the sand and dust.

After the air bubble cleaning part, there are high pressure spraying cleaning nozzles which could wash every angle of the gingers with turning over conveyor.

This assures thoroughly cleaning and better effect.

With double filters system, the water could be cycle used.

The spraying rinsing part should be connected to water supply and keep rising.



Good Features:

 The special ginger washing machine is configured with 2 parts cleaning:

1.Air bubble washing to wash and remove most of the sand, dirt and stones etc.

2. High pressure spraying cleaning part to clean the hard dirt etc attached on the ginger.

This part is configured with double layer conveyors: the top one is used for transfer the gingers while high pressure sprayed cleaning and the bottom conveyor for collecting the washed off dirt,dust,skins etc to release and will not be recycled in the water.

The water could be recycled used with good cleaning effect.



Item

Spec.

Model

JME6500

JME8000

JME10000

Motor

2.2kw

2.2Kw

2.2kw

Water pump

11kw

22kw

22kw

Air pump

3KW

3KW

3KW

Water consumption

3-4m3/h

Conveyor width

800/1000/1200mm

Water pressure

4-6 bar

Capacity

2-3 ton/h

5-7 ton/h

10 ton/h

Machine size

6500x1680x2200(mm)

8000x1680x2200(mm)

10000x1680x2200(mm)







China Joy Machinery and Equipment Limited is a professional manufacturer of food processing machines and high pressure cleaning equipment.

We are a comprehensive enterprise which integrates research,development,manufacture,installation and

maintenance.We have advanced equipment,rich experience,highly-qualified scientific researchers and professional staff members for the after-sales service.

We specialized in designing and producing fruit and vegetable processing line which is including fruit and vegetable washing machine,drying machine,peeling machine,slicing machine,chopping machine,sorting machine,mixing machine,and potato chips production line,meat processing line and high pressure cleaning pump,hydro test pump etc.

Our products had been exported to more than 60 countries,all the products had been gained high praise from the customers at home and abroad.

We will continue to follow the policy of quality first,reputation first,customer first.And sincerely hope to cooperate with much more customers all over the world.
